sc_signal and the Evaluate-Update Mechanism

If you've read the delta cycles article, you know that signal writes are deferred to the update phase. Now let's go deeper: why does sc_signal work this way, what does it actually look like in code, and what are the traps that catch engineers every day?

This article covers the full sc_signal<T> API — reads, writes, events, edge detection, the single-writer rule, and the dangerous implicit operators you should avoid.

1. Why sc_signal Exists — The Shift Register Problem

Consider a 4-stage hardware shift register. On every clock edge, each stage copies its value from the previous stage. In software, the order of assignments is everything:

// Software — order matters
Q4 = Q3;
Q3 = Q2;
Q2 = Q1;
Q1 = DATA;

If you flip the order, data shifts wrong. But in hardware, all four registers capture simultaneously — there is no ordering. In a SystemC simulation with four concurrent processes (one per register), the execution order is not guaranteed by the standard. Whichever process runs first will read a mix of old and new values, and the result depends on implementation.

The solution is the evaluate-update mechanism: writes are buffered during evaluate, and all updates are flushed simultaneously during the update phase. Every process reads the current (pre-update) value regardless of when it runs. Order stops mattering.

// SystemC — order doesn't matter — all read pre-update values
void reg4_process() { Q4_sig.write(Q3_sig.read()); }
void reg3_process() { Q3_sig.write(Q2_sig.read()); }
void reg2_process() { Q2_sig.write(Q1_sig.read()); }
void reg1_process() { Q1_sig.write(DATA.read()); }

2. Basic Syntax

// Declaration
sc_signal<int>    count_sig;
sc_signal<bool>   ready_sig;
sc_signal<string> msg_sig;

// Write (goes to new_value buffer — deferred)
count_sig.write(42);

// Read (returns current_value — always the pre-update value)
int val = count_sig.read();

// Wait for any value change
wait(count_sig.value_changed_event());

// Static sensitivity — trigger method on any change
sensitive << count_sig;

// Check if signal changed in the immediately previous delta
if (count_sig.event()) { /* changed last delta */ }

3. The Read Lag — Step by Step

This example shows exactly how the delta cycle delay manifests. Watch carefully as each wait(SC_ZERO_TIME) advances one delta:

int               count     = 0;
sc_signal<int>    count_sig;  // initial value: 0

// ── Delta 1 ──────────────────────────────────
count_sig.write(10);          // new_value = 10, current still 0
count = 11;                    // regular int: immediate

cout << count     << endl;    // → 11   (immediate)
cout << count_sig << endl;    // → 0    (still old!)

wait(SC_ZERO_TIME);            // trigger update: current ← 10

// ── Delta 2 ──────────────────────────────────
count_sig.write(count = 20);   // new_value = 20, current still 10

cout << count     << endl;    // → 20   (immediate)
cout << count_sig << endl;    // → 10   (last delta's write)

wait(SC_ZERO_TIME);            // trigger update: current ← 20

// ── Delta 3 ──────────────────────────────────
cout << count_sig << endl;    // → 20   (now visible)

4. Events — Knowing When a Signal Changes

sc_signal<T> provides three event-related methods. For a deeper look at how events and sensitivity work across all process types, see Events and Sensitivity in SystemC.

// Dynamic — wait in an SC_THREAD
wait(ready_sig.value_changed_event());

// Static — SC_METHOD retriggers on any change
SC_METHOD(on_change);
sensitive << ready_sig;   // same as << ready_sig.default_event()

// Inside on_change() — which signal triggered me?
void on_change() {
  if (ready_sig.event())  { /* ready_sig changed this delta */ }
  if (valid_sig.event())  { /* valid_sig changed this delta */ }
}

5. Edge Detection — posedge and negedge

For sc_signal<bool> and sc_signal<sc_logic> only, SystemC adds edge-detection methods that are essential for RTL-style clock modeling:

sc_signal<bool> clk;

// Events
wait(clk.posedge_event());     // wait for 0→1 transition
wait(clk.negedge_event());     // wait for 1→0 transition

// Static sensitivity
sensitive << clk.pos();        // shorthand for posedge_event()
sensitive << clk.neg();        // shorthand for negedge_event()

// Check inside a method
if (clk.posedge()) { /* rising edge occurred last delta */ }
if (clk.negedge()) { /* falling edge occurred last delta */ }

These don't exist on sc_signal<int> or other generic types — only on the boolean and logic specializations. sc_buffer<T> does not support posedge/negedge either.

6. The Single-Writer Rule

Only one process may write to a given sc_signal during a single delta cycle. If two processes both write to the same signal in the same evaluate phase, the behaviour is undefined. The OSCI simulator will flag this as a runtime error only if the DEBUG_SYSTEMC macro is defined at compile time.

// BAD — two processes both write to sig in the same delta
void process_A() { sig.write(1); }   // ← which one wins?
void process_B() { sig.write(0); }   // ← undefined behaviour

If your design genuinely needs multiple drivers — for example, a tri-state bus — use sc_signal_resolved or sc_signal_rv<N>, which support multiple writers and apply a built-in wired-AND/wired-OR resolution table.

7. sc_buffer — The Difference

sc_signal is just one type of channel in SystemC's hierarchy — see Evolution of Channels in SystemC for the full picture. Within that family, sc_buffer<T> is almost identical to sc_signal<T> with one key difference:

If you write the same value to an sc_signal twice in a row, no event fires the second time. With sc_buffer, the event always fires on write — useful when the act of writing is itself a meaningful trigger, regardless of value.

8. The Dangerous Implicit Operators

SystemC overloads the assignment and implicit conversion operators on sc_signal, which allows this syntax:

// Implicit — looks like a regular variable
sig = 42;           // calls write() — DANGEROUS
int x = sig;       // calls read() — mildly dangerous

Why dangerous? Consider this seemingly innocent code:

// r is sc_signal<int>, x=3, y=4, r=0 on entry
r = x;                          // write(3) → new_value=3, current=0
if (r != 0 && r != 1) r = r * r; // read()=0! 0*0=0 → write(0)
if (y != 0)           r = r + y*y; // read()=0, 0+16=16 → write(16)
cout << sqrt(r) << endl;        // → 0  (current still 0!)

Expected result: sqrt(3² + 4²) = 5. Actual result: 0. Every read returns the current value (0), not the value just written. The code looks like normal arithmetic but behaves completely differently because r is a signal.

9. sc_signal Full API Reference

Summary

• sc_signal<T> models hardware signals with deferred writes — it is not a variable.
• Writes go to a new value buffer; reads return the current value. They sync during the update phase.
• Reads after a write in the same evaluate pass return the old value — always.
• Use value_changed_event() to wait for changes; event() to check if change happened last delta.
• posedge_event()/negedge_event() only available on sc_signal<bool> and sc_signal<sc_logic>.
• Only one process may write a signal per delta cycle — enforce with -DDEBUG_SYSTEMC.
• sc_buffer<T> fires events on every write, even same-value — useful when write itself is the trigger.
• Avoid implicit = operators on signals — always use explicit .write() and .read().
